KIJANG INNOVA ZENIX HEV

Spesifikasi V Gasoline Luxury MT

Overall Panjang / Length (mm)	4.755	4.755	4.755
Overall Lebar / Width (mm)	1.850	1.850	1.850
Overall Tinggi / Height (mm)	1.795	1.795	1.795
Jarak Poros Roda / Wheelbase (mm)	2.850	2.850	2.850
Ground Clearance (G/C) (mm)	185	185	185
Jarak Pijak Depan / Front Tread (mm)	1.560	1.560	1.560
Jarak Pijak Belakang / Rear Tread (mm)	1.580	1.580	1.580

Mesin / Engine	M20A-FXS 4 cylinders, in-line 16-Valve DOHC, chain drive Dual VVT-i	M20A-FXS 4 cylinders, in-line 16-Valve DOHC, chain drive Dual VVT-i	M20A-FXS 4 cylinders, in-line 16-Valve DOHC, chain drive Dual VVT-i
Isi Silinder / Displacement (cc)	1.987	1.987	1.987
Diameter x Langkah / Bore x Stroke (mm)	80,5 x 97,6	80,5 x 97,6	80,5 x 97,6
Compression Ratio	14,0 : 1	14,0 : 1	14,0 : 1
Sistem Bahan Bakar / Fuel System	Direct injection, port injection D-4S system	Direct injection, port injection D-4S system	Direct injection, port injection D-4S system
Kapasitas Tangki / Fuel Tank Capacity (L)	52	52	52
Daya Maksimum / Maximum Power (ps/rpm)	186 (System), 152/ 6000 (Engine)	186 (System), 152/ 6000 (Engine)	186 (System), 152/ 6000 (Engine)
Daya Maksimum / Maximum Power (ps)	113 (Motor)	113 (Motor)	113 (Motor)
Torsi Maksimum / Maximum Torque (kgm/rpm)	19,1 / 4400-5200 (Engine)	19,1 / 4400-5200 (Engine)	19,1 / 4400-5200 (Engine)
Torsi Maksimum / Maximum Torque (kgm)	21 (Motor)	21 (Motor)	21 (Motor)

Drive System	2WD (FF)	2WD (FF)	2WD (FF)
Transmisi / Transmission	e-CVT	e-CVT	e-CVT
Suspensi Depan / Front Suspension	MacPherson Strut – Front / Torsion Beam – Rear	MacPherson Strut – Front / Torsion Beam – Rear	MacPherson Strut – Front / Torsion Beam – Rear
Stabilizer	Front & Rear	Front & Rear	Front & Rear
Brake	16 DISC	16 DISC	16 DISC
Parking Brake	Electric Parking Brake + Brake Hold	Electric Parking Brake + Brake Hold	Electric Parking Brake + Brake Hold
Tire & Disc Wheel	205/65 R16	215/60 R17	215/60 R17
Spare Tire	205/65R16 Steel	205/65R16 Steel	205/65R16 Steel
